ABB Drive Composer Pro is specialized software from ABB used for commissioning, configuring, monitoring, and maintaining ABB Common Architecture inverters such as ACS580, ACS880, ACS380, etc. The software allows engineers to connect directly to the inverter via USB, Ethernet, or communication network to configure and diagnose the system.
Key Features
Parameter Settings and Editing
View, edit, save, and restore all inverter parameters.
Compare different parameter sets.
Quick configuration backup/restore.
Real-time Monitoring
Monitor speed, current, torque, voltage, etc.
Display numerical or trend graph data.
Save data for later analysis.
Control the Inverter from a PC
Start/Stop.
Change set speed.
Switch between Local/Remote Control.
Fault Diagnosis
View Fault and Warning history.
Analyze the root cause of the problem.
Monitor I/O status and internal signals.
Control Diagram
Display the inverter control block diagram.
Monitor signal flow similar to online monitoring in a PLC.
Adaptive Programming
Create simple logic programs inside the ABB inverter.
Perform calculations, conditions, and timers without an external PLC.
Working with Multiple Inverters
Connect and monitor multiple drives simultaneously via Ethernet/Fieldbus network. (Pro version only)
Supported Models
Drive Composer Pro supports working with the following models: ACS180, ACS380, ACS480, ACS530, ACS560, ACS580, ACS580MV, ACS860, ACS880, ACS6080, ACH480, ACH531, ACH580, ACQ531, ACQ580, DCS880, DCT880, HES880.
Software Download Link
1. Download via GoogleDrive
>>> Download Drive Composer Pro Full Software
Password Extract: plctop.com
Note: Contact ABB to purchase a license and receive the best support from the manufacturer.
If you are a student and need to use “Drive Composer Pro” for learning and experimentation, please contact plctop.com via the email address: plctop.com@gmail.com
